Sugden Masterclass IA-4 Integrated Amplifier
The Sugden Masterclass IA-4 is Sugden's flagship and most popular integrated amplifier. Weighing a substantial 20 kilos the IA-4 has a purposeful look and impressive build quality. Plenty of input and output facilities are on offer including a high quality phono stage. The class A power output circuit has been upgraded from the A21 series with a larger power supply and improved soothing and output capacitors. Gold plated circuit boards, full relay switching and a precision input selector switch offer further detailing. The pre-amplifier section of the IA-4 is a bespoke design, with surprising clarity and detail. The most noticeable feature is the ability to create a large performance with depth and height on any type of music.
Specifications
| Inputs: | Three line level, tape, MM phono, balanced |
| Outputs: | Variable pre-out, fixed out, loudspeaker out |
| Volume Control: | Remote control RC5 Compatible |
| Recording: | Monitor and record off |
| Line Input Sensitivity: | 125 mV |
| Phono Input Sensitivity: | 2 mV (MM) |
| Power Output: | 33 Watts per channel into 8 Ohms |
| Frequency Response: | +/-1 dB 14 Hz-200 kHz |
| Bandwidth: | 6 Hz-300 kHz |
| Signal to Noise: | >84 dB |
| Gross Weight (packed): | 20 kg |
| Dimensions (H x W x D): | 165 × 430 × 440 mm |
