KEF Ci160TS In-Ceiling/Wall Square Speaker
Boasting the latest incarnation of KEF's formidable 4.5in. mid/bass T Series driver and powerful 1in. tweeter, the ultra-slim Ci-T Series speakers open up new possibilities for enjoying KEF's uncompromised sound quality where installation space is at a premium.
Requiring less than 36mm of mounting depth, the Ci160TS fits snugly in very narrow ceiling or wall spaces and is therefore specified for demanding applications such as today's luxury high-rise apartments or your music system.
Features
- <36mm mounting depth allows fitment to very restricted cavities
- Ultra-low profile LF unit with excellent bass extension
- Vented tweeter with KEF's unique 'tangerine' waveguide for natural HF response and wide, even dispersion
- Rigid flat diaphragm assures clean upper bass and mid-range response
- Paintable Ultra-Thin Bezel (UTB) and magnetic grille to blend unobtrusively with décor
- Fast, versatile installation on virtually any surface via dogleg
Specifications
| Nominal Impedance: | 8 Ohm |
| Sensitivity: | 87dB (2.83V/1m) |
| Crossover Frequencies: | 1.7kHz |
| Frequency Response: | 110Hz - 24kHz (+/-6dB) open-backed |
| Drive Units: | LF: 115mm (4.5in. Dual layer) HF: 25mm (1in.) |
| Recommended Amplifier Power: | 10-100W |
| Product External Dimension (H x W x D): | Diameter: 222.8 x 222.8 mm (8.77 x 8.77 in.) Depth: 41mm (1.61in.) |
| Cut-Out Dimensions (H x W): | 194 x 194 mm (7.64 x 7.64 in.) |
| Mounting Thickness: | Ceiling Thickness (Maximum): 26mm (1.03 in.) Ceiling Thickness (Minimum): 9mm (0.36 in.) |
| Mounting Depth From Surface: | <36mm (1 7/16in.) |
| Optional Rough In Frame: | RIF160S |
| Optional Rear Enclosure: | RNC160S |
| Net Weight: | 1.05kg (2.31lbs) |
| Unit Measurement: | Singular |
